Orifice Welding Neck Class 300

Ürün Açıklaması

Welding neck orifice flanges are special flanges used to measure the flow rate in pipelines. Used in conjunction with an orifice plate, they provide high accuracy in flow measurement.

Standards and Material:

Standards: ASME B16.5
Pressure Class: Class 150-600
Size Range: ½" - 24"

Kullanım Alanları

These flanges are preferred in industrial systems due to their design that minimizes pressure drop, high strength, and easy installation features.

Oil and natural gas pipelines
Chemical and petrochemical plants
Power plants
Flow measurement and control systems

Kalite ve Sertifikasyon

Medisan Orifice Flanges are manufactured in accordance with the ASME B16.5 standard and hold PED 2014/68/EU and BV Factory Approval certifications. Material options include carbon steel (ASTM A105), stainless steel (ASTM A182 F304/F316), and alloy steels (ASTM A182 F11/F22).

ASME B16.36-2020

Dimensions are in millimeters.
