Slip On Flanges Class 300

360° View

Product Description

Slip-On Flanges are a type of flange that creates a leak-proof and high-strength connection by sliding the pipe into the flange hub and welding it from both the inside and outside. Offering higher pressure and temperature resistance compared to the Class 150 series, these flanges are frequently preferred in industrial facilities due to their ease of alignment during installation and tolerance for pipe length.

Standards and Material:

Standards: ASME B16.5 - Class 300
Material: ASTM A105 (Carbon Steel), A182 F304/F316 (Stainless Steel), A182 F11/F22 (Alloy Steel)
Face Types: RF (Raised Face), FF (Flat Face), RTJ (Ring Type Joint)
Size Range: ½" - 24"

Applications

These flanges are safely used generally in medium and high-pressure steam lines, oil and gas distribution systems, chemical process lines, and hydraulic systems.

Quality and Certification

Slip-On Flanges manufactured by Medisan are fully compliant with the ASME B16.5 standard and offer superior performance in the Class 300 pressure class. Each product is under quality assurance with PED 2014/68/EU, ISO 9001:2015, and Class BV Factory Approval certifications.

ASME B16.5-2020

MSS SP-44-2019

BS 3293

Dimensions are in millimeters.
