45° Latrolet

360° View

Product Description

Product Description: The 45° branch outlet (Latrolet) is a special fitting that connects to the main pipeline at a specific angle (usually 45°) to create a branch outlet. This design minimizes pressure loss in the line while changing the flow direction. 45° branch outlets manufactured by Medisan are produced in full compliance with ASME B16.11 and MSS-SP-97 standards.

Applications

Preferred especially in high-pressure piping systems in the oil, gas, and chemical industries.

Quality and Certification

All production processes are controlled under PED 2014/68/EU and Class BV Factory Approval certifications. Our products are offered in carbon steel, stainless steel, and alloy steel options in Class 3000, 6000, and 9000 pressure ratings.

MSS SP-97-2019

Dimensions are in millimeters.

Also available for run sizes through 36”. x=(0D/2+Root Gap)/.7071 +E
