Blind Flanges Class 2500

Ürün Açıklaması

Blind Flanges are a type of flange used to securely close the ends of a pipeline or pressure system. They ensure sealing at line terminations, allow for temporary closure of the system during maintenance, and provide safety in high-pressure applications.

Standards and Material:

Standards: ASME B16.5
Pressure Class: Class 150-2500
Material: ASTM A105 (Carbon Steel), A182 F304/F316 (Stainless Steel)
Size Range: ½" - 48"

Kullanım Alanları

These flanges are ideal specifically for oil and gas lines, refineries, chemical plants, and pressure equipment systems.

Kalite ve Sertifikasyon

Medisan Blind Flanges are manufactured in accordance with the ASME B16.5standard and are under quality assurance with PED 2014/68/EU and BV Factory Approval. Material options include carbon steel (ASTM A105), stainless steel (ASTM A182 F304/F316), and alloy steels (ASTM A182 F11/F22).

ASME B16.5 -1996

MSS SP-44-2019

B16.47-A / B16.47-B

Dimensions are in millimeters.
