“We are here to provide you with reliable and high-quality solutions.”

Excellence in Steel with 25 Years of Experience


We offer high-quality forged steel pipe fittings, butt-weld pipe connectors, and forged steel flanges tailored to meet your industrial needs. Shaped by years of expertise, our products ensure the perfect balance of durability, safety, and performance. Our goal is to be your trusted partner by providing the best solutions for your projects, where quality and reliability meet.

Excellence in Steel with 25 Years of Experience


We offer high-quality forged steel pipe fittings, butt-weld pipe connectors, and forged steel flanges tailored to meet your industrial needs. Shaped by years of expertise, our products ensure the perfect balance of durability, safety, and performance. Our goal is to be your trusted partner by providing the best solutions for your projects, where quality and reliability meet.

25

YEARS

EXPERIENCE

25

YEARS

EXPERIENCE

Corporate

Corporate

FORGED STEEL PIPE FITTINGS

FORGED STEEL PIPE FITTINGS

FORGED STEEL PIPE FITTINGS

PRODUCT

PRODUCT

PRODUCT

All our forged pipe fittings are supplied with test certificates as per EN 10204 3.1, with complete certifications of raw materials.

All our forged pipe fittings are supplied with test certificates as per EN 10204 3.1, with complete certifications of raw materials.

All our forged pipe fittings are supplied with test certificates as per EN 10204 3.1, with complete certifications of raw materials.

An ISO 9001:2015 Certified Company,

An ISO 9001:2015 Certified Company,

An ISO 9001:2015 Certified Company,

Offers a range of

Mechanical Testing, Hydro Testing, and Non-Destructive Testing such as PMI, Ultra Sonic, Radiography, and Hardness to client specifications.

Offers a range of

Mechanical Testing, Hydro Testing, and Non-Destructive Testing such as PMI, Ultra Sonic, Radiography, and Hardness to client specifications.

Offers a range of

Mechanical Testing, Hydro Testing, and Non-Destructive Testing such as PMI, Ultra Sonic, Radiography, and Hardness to client specifications.

Medisan is one of the leading manufacturers of high quality Forged SteelFttings in all major grades including ASTM A182, A105, A105N, A350 LF2, A182 F5, A182 F9, A182 F11,A182 F22, A182 F91. Our stainless steel and carbon steel ANSI Forged Fittings are available in 2000#, 3000#,6000#, and 9000# pressure ratings and in either socket weld as or threaded ends.“

Medisan is one of the leading manufacturers of high quality Forged SteelFttings in all major grades including ASTM A182, A105, A105N, A350 LF2, A182 F5, A182 F9, A182 F11,A182 F22, A182 F91. Our stainless steel and carbon steel ANSI Forged Fittings are available in 2000#, 3000#,6000#, and 9000# pressure ratings and in either socket weld as or threaded ends.“

Medisan is one of the leading manufacturers of high quality Forged SteelFttings in all major grades including ASTM A182, A105, A105N, A350 LF2, A182 F5, A182 F9, A182 F11,A182 F22, A182 F91. Our stainless steel and carbon steel ANSI Forged Fittings are available in 2000#, 3000#,6000#, and 9000# pressure ratings and in either socket weld as or threaded ends.“

Other specific testing or certification requirementscan be provided upon request. We are capable ofsupplying the 3000# and 6000# forged fittingswith the shortest lead times. Our stock of ASTM/ASME SA105N Forged Carbon Steel ranges from1/8’’ to 4’’NB, 3000# and 6000# Screwed NPTor BSPT and Socket Weld. The forged fittings arealso offered with additional surface coatingssuch as Sand Blast Finish, Blackodised Finish,Electro Zinc, Aluminised, Phosphated, Self Colour,and with Hot Dip Galvanising.

Other specific testing or certification requirementscan be provided upon request. We are capable ofsupplying the 3000# and 6000# forged fittingswith the shortest lead times. Our stock of ASTM/ASME SA105N Forged Carbon Steel ranges from1/8’’ to 4’’NB, 3000# and 6000# Screwed NPTor BSPT and Socket Weld. The forged fittings arealso offered with additional surface coatingssuch as Sand Blast Finish, Blackodised Finish,Electro Zinc, Aluminised, Phosphated, Self Colour,and with Hot Dip Galvanising.

Other specific testing or certification requirementscan be provided upon request. We are capable ofsupplying the 3000# and 6000# forged fittingswith the shortest lead times. Our stock of ASTM/ASME SA105N Forged Carbon Steel ranges from1/8’’ to 4’’NB, 3000# and 6000# Screwed NPTor BSPT and Socket Weld. The forged fittings arealso offered with additional surface coatingssuch as Sand Blast Finish, Blackodised Finish,Electro Zinc, Aluminised, Phosphated, Self Colour,and with Hot Dip Galvanising.

Forged Steel High Pressure Fittings

Forged Steel High Pressure Fittings

Pressure Class

2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Socket Weld Forged Steel Fittings

Elbow 90°, Elbow 45°, Tee, Cross, Union, Coupling, Half Coupling, Cap, Boss, Outlet, Welding Outlet, Insert

Threaded Forged Steel Fittings Products

Elbow 90°, Elbow 45°, Street Elbow 90°, Tee, Cross, Union, Coupling, Half Coupling, Reducing Coupling, Cap, Hex .Head Bushing, F/M Reducer, Hex. Head Plug, Square Head Plug, Round Head Plug, Boss, Threaded Outlet, Nipple Outlet, Hex. Nipple, Swage Nipple

Dimension Specifications

ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799

Size

1/8”~4” (DN6~DN100)

Forged Steel Fittings Threaded and Socket Weld

Forged Steel Fittings Threaded and Socket Weld

Forged Steel Fittings Threaded and Socket Weld

Stainless Steel

Stainless Steel

ASTM A182 F304, F304L, F306, F316L, F304H, F309S, F309H, F310S, F310H, F316TI, F316H, F316LN, F317, F317L, F321, F321H, F11, F22, F91, F347, F347H, F904L, ASTM A312/A403 TP304, TP304L, TP316, TP316L

ASTM A182 F304, F304L, F306, F316L, F304H, F309S, F309H, F310S, F310H, F316TI, F316H, F316LN, F317, F317L, F321, F321H, F11, F22, F91, F347, F347H, F904L, ASTM A312/A403 TP304, TP304L, TP316, TP316L

The material for forged stainless steel fittings conforms to ASME A182

The dimensions for forged stainless steel fittings conform to ASME B16.11

NPT Threads conform to ASME B1.20.1

The material for forged stainless steel fittings conforms to ASME A182

The dimensions for forged stainless steel fittings conform to ASME B16.11

NPT Threads conform to ASME B1.20.1

Forged Steel Socket Weld

Threaded Fittings

Forged Steel Socket Weld

Threaded Fittings

Carbon Steel ASTM A105, A350 LF2, A106 Gr.B, A234 WPB The material for forged carbon steel fittings conforms to the requirements of ASTM/ASME A105/SA105 The dimensions for forged carbon steel fittings conform to ASME B16.11 NPT Threads conform to ASME B1.20.1

Carbon Steel ASTM A105, A350 LF2, A106 Gr.B, A234 WPB The material for forged carbon steel fittings conforms to the requirements of ASTM/ASME A105/SA105 The dimensions for forged carbon steel fittings conform to ASME B16.11 NPT Threads conform to ASME B1.20.1

BUTTWELD PIPE FITTINGS

BUTTWELD PIPE FITTINGS

BUTTWELD PIPE FITTINGS

PRODUCT

PRODUCT

PRODUCT

Welded Buttweld Pipe Fittings

Seam welded buttweld fittings are produced from hot rolled stainless steel pipes. As per customer requirements, we can also manufacture and offer butt weld fittings manufactured from hot rolled plates, formed into half shells or segments and then welded on the seams.

Welded Buttweld Pipe Fittings

Seam welded buttweld fittings are produced from hot rolled stainless steel pipes. As per customer requirements, we can also manufacture and offer butt weld fittings manufactured from hot rolled plates, formed into half shells or segments and then welded on the seams.

Seamless Buttweld Pipe Fittings

Seamless buttweld pipe fittings are manufactured from seamless pipes and tube by hot or cold extrusion, forming and machining process.

Seamless Buttweld Pipe Fittings

Seamless buttweld pipe fittings are manufactured from seamless pipes and tube by hot or cold extrusion, forming and machining process.

ANSI / ASME B16.9 / MSS SP 43

Buttweld Pipe Fittings Production Range

Size Range

1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Product Range

Elbow 90°, Elbow 45°, Tee, Concentric Reducer, Eccentric Reducer, Cap

Thickness

SCH: 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS, Custom Thickness.

Buttweld Fittings - Manufacturing Standards

ASME

ANSI B16.9, ANSI B16.28, MSS-SP-43

DIN

DIN2605, DIN2615, DIN2616, DIN2617, DIN28011

EN

EN10253-1, EN10253-2

Buttweld Fittings Grades

Stainless Steel Buttweld Pipe Fittings

ASTM A403 WP 304 / 304L / 304H / 316 / 316L / 317 317L / 321 / 310 / 347 / 904L / 2205 Duplex Fittings

Carbon Steel Buttweld Pipe Fittings

ASTM A234 WPB / A420 WPL3 / A420 WPL6 / MSS-SP-75 WPHY 42 / 46 / 52/ 56 / 60 / 65 / 70

Alloy Steel Butt Weld Pipe Fittings

ASTM A234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91

Other Materials

Monel, Nickel, Inconel, Hastelloy, Copper, Brass, Bronze,Titanium, Tantalum, Bismuth, Aluminium, Zinc, Lead, etc.

Copper Nickel Butt Weld Pipe Fittings

CuNi10Fe1Mn, CuNi30Mn1Fe

FORGED STEEL FLANGES

FORGED STEEL FLANGES

PRODUCT

PRODUCT

PRODUCT

A flange is a method of connecting pipes, valves, pumps andother equipment to form a piping system. It also provides easyaccess for cleaning, inspection or modification.

A flange is a method of connecting pipes, valves, pumps andother equipment to form a piping system. It also provides easyaccess for cleaning, inspection or modification.

Medisan makes forged steel and fully machined flangesthat meet the ASME B16.5, ASME B16.47, and MSS SP-44standards.

Medisan makes forged steel and fully machined flangesthat meet the ASME B16.5, ASME B16.47, and MSS SP-44standards.

Size

1/2” (15 NB) to 48” (1200NB)

Standards

• ANSI B16.5 • ANSI B16.47 Series A & B • MSS SP44 • Custom Drawings

Pressure Ratings

Class 150 | Class 300 | Class 400 | Class 600 | Class 900 | Class1500 | Class 2500 PN6 | PN10 | PN16 | PN25 | PN40 | PN64 etc.

Types of Flanges

Weld neck Flanges (WNRF) | Slip-on Flanges (SORF) | Blind Flanges (BLRF) | Lap Joint Flanges (SOLJ) | Socket-weld Flanges (SWRF) | Screwed (Threaded) Flanges | Long weld neck Flanges (LWNRF) | Spectacle Blind Flanges Spacer & Blind Flanges | Ring Type Joint Flanges (RTJ) | Reducing Flanges | Raised Face (RF) Flanges | Orifice Flanges | Large Diameter Flanges | Custom Flanges | Drawing Flanges | Forged Flanges | Plate Flanges | Flat Face Flanges, etc.

Carbon Steel Flanges

ASTM A105/A105N | A350 LF1 | LF2 CL1/CL2 | LF3 CL1/CL2 | A694 F42 | F46 | F48 | F50 | F52 | F56 | F60 | F65 | F70 | A516.60, 65 | 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange) | Steel RST37.2, C22.8

Stainless Steel Flanges

ASTM A182 F202 | F304/304L/304H | F316/316L | F316H | F316TI | F310 | F321 | F904L Alloy Steel Flanges: ASTM A182 F1 | F5 | F9 | F11 | F22 | F91

Flange Face Type

• Flate Face (FF) • Raised Face (RF) • Ring Type Joint (RTJ)

Coating-Surface Treatment

• Anti-rust Paint • Oil Black Paint • Yellow Transparent • Zinc Plated • Cold and Hot Dip Galvanized
